Hand scaling
Basic
Anterior sickle scaler
Design characteristics:
Triangular cross-section
Pointed tip and back
Two-cutting edges
Face-terminal shank angulation of 90°
![](https://www.iperiopal.com/wp-content/uploads/2020/04/anterior.jpg)
![](https://www.iperiopal.com/wp-content/uploads/2020/04/Supragingival.png)
Indication for use:
Supragingival debridement of the upper and lower anterior teeth
![](https://www.iperiopal.com/wp-content/uploads/2020/04/anterior2.jpg)
Right handed
Always start at or close to the mid-line and proceed towards mesial or distal surface of the tooth
Facing surfaces
(right handed operator at 8 o’clock)
Averted surfaces
(right handed operator at 12 o’clock)
Left handed
Always start at or close to the mid-line and proceed towards mesial or distal surface of the tooth
Facing surfaces
(left handed operator at 3 – 4 o’clock)
Averted surfaces
(left handed operator at 12 o’clock)
Angulation
![](https://www.iperiopal.com/wp-content/uploads/2020/04/ANangulation.png)
Angulation is achieved by
tilting the lower shank slightly towards the tooth surface.
This creates a face-to-tooth surface angulation of 60 to 80 degrees.
Anterior sickle scaler angulation
Use the terminal shank as a visual clue!!!
Adaptation
![](https://www.iperiopal.com/wp-content/uploads/2020/04/AnAdaptation.png)
![](https://www.iperiopal.com/wp-content/uploads/2020/04/AnAdaptation2.png)
Correct working end
Posterior sickle scaler
Angulation
Correct angulation and adaptation of the instrument
(sickle scaler)
Use the terminal shank as a visual clue!!!
![](https://www.iperiopal.com/wp-content/uploads/2020/04/POAngulation.png)
Adaptation
Correct working end
Correct working end of the instrument
Compare the two working ends
![](https://www.iperiopal.com/wp-content/uploads/2020/04/Picture8-e1586199151507.jpg)
![](https://www.iperiopal.com/wp-content/uploads/2020/04/Picture9_1.jpg)
Correct working end
(sickle scaler)
![](https://www.iperiopal.com/wp-content/uploads/2020/04/Correctwe.png)
